Application
Designed for the filtration of aluminium and aluminium-alloy melts, effectively removing oxides, slag and non-metallic inclusions.
Aluminium filtration solution
Alumina Based Ceramic Foam Filters
Our alumina ceramic foam filters are manufactured using a precision replication process to create a uniform, open-pore structure. Their excellent chemical stability enables reliable filtration without reacting with molten aluminium.
The tortuous pore network captures oxides, slag and other non-metallic inclusions while regulating metal flow. This promotes cleaner, smoother castings and consistent performance at aluminium pouring temperatures.
Key advantages
- Improved surface finish
- Reduced porosity and inclusions
- Enhanced mechanical properties
- Stable performance at pouring temperatures
Key Benefits
- Improved surface finish
- Reduced porosity and inclusions
- Enhanced mechanical properties
- Stable performance at aluminium pouring temperatures
Material Characteristics
Alumina-based ceramic foam filters offer excellent chemical stability and a uniform pore structure, ensuring reliable filtration and controlled metal flow.
Product
performance
Technical Specifications
Standard properties of our alumina (Al2O3) ceramic foam filters.
| Property | Typical Value |
|---|---|
| Material | Alumina (Al2O3) |
| Color | White |
| Pore Size | 10–30 PPI |
| Porosity | 75–80% |
| Bulk Density | 0.45 ± 0.05 g/cm³ |
| Compressive Strength | ≥ 0.8 MPa |
| Maximum Working Temperature | 1,100°C |
| Thermal Shock Resistance | Good |
| Recommended Metals | Al-Si, Al-Mg and Al-Cu alloys |
Available shapes: square,
rectangular and roundCustom sizes available on
request
Need detailed technical data?
Complete data sheets and custom-size information are available on request.
